CK-003ProMax
CK-003ProMax Smart Tea Brewer
2000 cc capacity-class tea brewer with a rotary pump and a 3000W power specification. Confirm the working brew volume and recipe cycle before ordering.
Product specifications
Published model and source-sheet data. Configuration ranges and listed timings depend on the selected version and operating conditions. Source-sheet dimensions are reference measurements, not confirmed current delivery dimensions. Confirm the final configuration, electrical supply and supplied accessories before ordering.
- Model
- CK-003ProMax
- Pump type
- rotary
- Power
- 3000W
- Capacity class
- 2000 cc
- Voltage
- 110-220V wide-voltage design
- Color
- Black / white
- Temperature control
- PID control, ±1°C
- Pressure gauge
- Round gauge, standard
- Source-sheet dimensions (L × W × H)
- 270 × 629 × 509 mm
CK smart tea brewer series
Consistent tea extraction, from a single cup to batch preparation.
CK smart tea brewers combine a pump system with a smart control module to reproduce a tea master’s technique. Water temperature, time, pressure and flow are controlled precisely, so every batch is bright in colour, clean in aroma and consistent in taste — improving both drink quality and serving speed.
Core features
- Smart extraction programsPreset programs for teas such as green, black and oolong. Select one and the brewer runs the water temperature, time and extraction sequence automatically. Ten cup-volume programs can be stored.
- Professional pump technologyVibration pump: quick start and compact build. Rotary pump: steady pressure, low noise and long service life for a gentler, more consistent extraction. Adjustable pressure: set the pressure to suit delicate green teas or strong, high-pressure brews.
- T3 temperature controlPID control holds water temperature to ±1°C. Boiler (T1), steam (T2) and brew-head (T3) temperatures are set separately to bring out each tea’s aroma.
- Flexible capacityFrom single cups of about 300–500 ml to 2000 cc and 5000 cc batches, covering both peak-hour made-to-order drinks and advance preparation.
- Segmented pressure profilesOn the adjustable-pressure model, set different pressure stages for different teas, recipes and herbal blends to extract deeper flavour and a higher yield.
- Your brand on the machineThe touchscreen interface and the acrylic side-panel logo can be customised for your brand. The menu switches between English and Chinese with one tap.
Appearance and key parts
- 7-inch touchscreen The interface can be changed to show your brand or logo.
- Brew-head handle (brown wood) Loads and removes the tea basket; fitted on every model.
- Round pressure gauge Standard on CK-002, CK-003, CK-004 and CK-005; CK-001 has no gauge.
- Power switch On the right side of the head; the light shows the machine is on.
- Acrylic side panel The logo can be customised for your brand.
- Water inlet at the rear left Marked “Water Enter”; connect a tap-water or purified-water line.
Compare the series
All models: 110–220V wide-voltage design, black and white finish.
| Model | Pump | Capacity | Power | Settings menu | Best for |
|---|---|---|---|---|---|
| CK-001Air | Vibration pump | Single cup | 3000W | 3 settings entries | Fast, efficient single-cup extraction. |
| CK-002Pro | Rotary pump | Single cup | 4000W | 3 settings entries | Steadier pressure and gentler extraction for premium single cups. |
| CK-003ProMax This model | Rotary pump | 2000 cc | 3000W | 10 settings functions | Large-capacity extraction for tea preparation in advance. |
| CK-004Ultra | Rotary pump | 5000 cc | 4200W | 3 settings entries | Stable pressure at 5000 cc for daily commercial volume. |
| CK-005UltraMax | Adjustable-pressure rotary pump | 5000 cc | 4200W | 10 settings functions | Pressure tuned to each tea for professional, customised extraction. |
| CK-C01 | — | Built-in unit | 4000W | — | Space-saving built-in design with a highly integrated, clean finish. |
Basic operation
- Preheat: make sure the tank holds enough suitable water, switch on and wait for heating to finish. Never heat the boiler dry.
- Choose a program such as “Black tea” or “Green tea”. Models with a custom mode also let you set water temperature, extraction time and pre-infusion time.
- Load a measured amount of tea into the brew handle; grind strong teas and herbal blends for better extraction. Place a teapot or measuring cup under the outlet.
- Press Start. The brewer pre-infuses, extracts under pressure and stops automatically. Do not move or open the tea chamber during extraction.
- Remove the tea leaves straight away and rinse the filter basket. Run the cleaning program at the end of each business day.
Installation and safety
- Electrical: the brewer draws high power. Use a dedicated, properly earthed circuit and socket; no power strips or sockets shared with other high-power equipment. Confirm your local mains voltage before installation.
- Water: filtered or purified water is strongly recommended. Untreated tap water causes scale that can block pipes, damage the pump and heater and affect taste.
- Placement: a stable, solid, heat-resistant and well-ventilated level counter with clearance for cooling, away from flammable materials. Built-in models must be installed by a professional.
- Heat and pressure: the boiler, outlet and pipes are hot and pressurised in use. Do not open the cover or touch the outlet while running; cool down and release pressure before draining or cleaning.
- First use: fill the tank with clean water and run one full cleaning cycle without tea. Operators should read the manual and receive basic training.
Product overview
CK-003ProMax Smart Tea Brewer
The CK-003ProMax is listed as a 2000 cc tea brewer with a rotary pump and 3000W power. Its 2000 cc capacity class is a useful model-selection reference, while the actual working brew volume and preparation cycle should be confirmed for the tea recipe you intend to use.
Product specifications
- Model: CK-003ProMax.
- Capacity class: 2000 cc.
- Pump type: rotary.
- Power specification: 3000W.
Plan the tea preparation cycle
Share the tea type, recipe, desired prepared volume and peak demand with your inquiry. Ask for the usable working volume, supported recipe controls, temperature range and extraction cycle. Confirm how the prepared tea is collected and how the equipment is cleaned between recipes. Do not use the capacity-class number as a substitute for a confirmed hourly output.
Installation considerations
Check the machine dimensions, operating clearances and space for the receiving container against your counter layout. Confirm inlet water quality, filtration, water connection and drainage requirements. Request the voltage, frequency, plug and electrical circuit specification for the quoted machine before preparing the site.
Request a quotation
Provide CK-003ProMax, quantity, destination, intended tea recipes, required working volume and available counter space. Ask for confirmation of the exact configuration, accessories, installation requirements and delivery terms.
Frequently asked questions
What capacity class is specified?
The CK-003ProMax is listed as a 2000 cc tea brewer. Confirm the usable working brew volume for your recipe.
Which pump is used?
A rotary pump is specified.
How much tea can it produce per hour?
Request the working volume and cycle time for your recipe. An hourly output is not specified here.
What power specification is available?
3000W. Voltage, frequency and connection requirements must be confirmed for the quoted configuration.
